BAY-H系列防爆環形熒光燈(IIB、IIC)
|
|
| |
|
適用范圍
1、1區、2區危險場所。
2、ⅡA、ⅡB、ⅡC類爆炸性氣體環境。
3、配裝光源，環形熒光燈管。
＊要求ⅡC類時請注明。
Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.
3、Equipped with light source, annular fluorescent lamp.
*Please note if need Ⅱ C grade needed. |
產品特點
1、鑄鋁合金外殼，表面噴塑。
2、鋼化玻璃燈罩。
3、鋼管或電纜布線均可。
4、可根據用戶要求配裝應急裝置。
5、符合GB3836-2000，IEC60079標準要求。
Features
1、Diecasted Al-alloy shell with plastic sprayed surface.
2、The lampshade is made of toughened glass.
3、Suitable for both steel pipe and cable wiring.
4、Can be made to add emergency device as required.
5、Suitable for GB3836-2000, IEC60079 standard request. |
|
|
| |
|
 |
| 吸頂式 吊桿式 |
|
 |
| |
|
| 主要技術參數 Main technical parameters |
|
額定電壓 |
額定功率 |
防爆標志 |
進線口螺紋 |
電纜外徑 |
質量 |
220 |
22x2 |
Exd II BT6
Exd II CT6 |
3/4 |
10-14 |
8 |
|
|
| |
|
應急起動時間 |
充電時間 |
應急照明時間 |
0.3 |
24 |
90 |
|
|
| |
|
| |
|
