BAT51系列防爆投光燈(IIB、IIC)


適用范圍
1、1區、2區危險場所。
2、ⅡA、ⅡB、ⅡC類爆炸性氣體環境。
3、可配裝汞燈、高壓鈉燈、金鹵燈。
*要求ⅡC類時請注明。


Application
1、Can be used in Zone 1 and Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.
3、Suitable for mercury vapor lamp, high-pressure sodium vapor
lamp, metal halide lamp.
*Please note if need Ⅱ C group.

產品特點

1、鑄鋁合金外殼,壓鑄成形,表面噴塑。
2、燈體可在水平旋轉360°,仰角在+90°
至-60°內可調。
3、反射罩采用拋物面形狀,反射率高,針對
250W功率設有調焦機構,可實現遠近調
節,遠光時,射程能達100m。
4、有較強的防水性能,可使用于船舶或石油平
臺等有較高防護要求的場所供照明之用。
5、電纜布線。
6、符合GB3836-2000,IEC60079標準要求。

Features
1、Diecasted aluminium alloy shell with plastic-sprayed surface.
2、The lamp body can be rotated 360° levelly and adjusted from +90°to
-60°elevately.
3、The reflector uses paroboloid shape, high reflectivity, aim at 250W power, it
has adjusting focus organization can realize hear and for adjustment, it can
reach 100m when it is far hight.
4、 With high performance of water-proofing and applicable to use in the place to illuminate that have higher protection demand, such as ship, petroleum platform, etc.
5、Suitable for cable wiring.
6、Suitable for GB3836-2000, IEC60079 standard request.



主要技術參數 Main technical parameters
防爆標志
防護等級
電纜外徑
進線口螺紋
燈座代號
Exde II BT3
Exde II CT3
IP55
10-14
3/4
E40


配用光源 Supplied with lamps
光源類型
目鎮汞燈
高壓汞燈
高壓鈉燈
金鹵燈
額定電壓(V)
220
額定功率(W)
250
175
150
175
250
250
250
450
400
400
400
1000
