BAD56-系列防爆防腐燈(不銹鋼)(e、n)


適用范圍
1、2區(qū)危險場所。
2、ⅡA、ⅡB、ⅡC類爆炸性氣體環(huán)境。
3、可配裝白熾燈、汞燈、鈉燈、金鹵燈等光源。
注:當用作增安型時,不配鈉燈。


Application
1、Can be used in Zone 2 dangerous places.
2、Can be used in ⅡA、ⅡB、ⅡC group explosive atmosphere.
3、Suitable for incandescent lamp, mercury vapor lamp, high-pressure
sodium vapor lamp, metal halide lamp.
Note:If it is safety-increased type, it is not suitable for sodium vapor lamp.

產品特點

1、外殼采用不銹鋼拉伸成型,外形美觀。
2、采用扣合式快速開啟結構,更換燈泡方便,密
封可靠,具有較強的防水、防塵、防腐功能。
3、鋼管布線。
4、符合GB3836-2000,IEC60079標準要求。

Features
1、The shell stretch-formed by stainless steel with anestic appearance.
2、Use buckle type fist opening up structure, which is convenient for changing
bulb, sealed and secure having the functions of strong water-proof, dust-proof,
corrosion-proof.
3、Suitable for steelpipe.
4、Suitable for GB3836-2000, IEC60079 standard request.



主要技術參數 Main technical parameters
防爆標志
防護等級
防腐等級
電纜外徑
進線口螺紋
燈座代號
Exe II T3
Exn II T3
IP65
WF2
10-14
3/4
E27
E40


配用光源 Supplied with lamps
光源類型
目鎮(zhèn)汞燈
白熾燈
高壓汞燈
金鹵燈
高壓鈉燈
額定電壓(V)
220
額定功率(W)
125 160 250
200 300
80 125 250
70 100 175 250
70 110 150 250
